Coach
Churchward
Churchward Bogie Gangway Full Brake (BG) Multibar Toplight Snake C (Diagram K22)
Extant Stock:
Number Range: W257W - W266W (10). Built Swindon Sep 1921 - Apr 1922 to Lot 1281.
Number Range: W1129W - W1153W (24). Built Swindon Nov 1921 - Nov 1922 to Lot 1301.
W1145W - Renumbered 079038 and converted for internal use in 08/1960. Withdrawn in1973
W1150W - Renumbered DW150241 and converted to a Drying Van in 01/1960. Withdrawn in1984. Last use as Mess Van for Severn Tunnel train. Condemned Radyr.
| Diagram | K22 |
| Introduced | 1915 |
| Builder | GWR Swindon |
| Length | 56' 11" |
| Width | 8' 11" |
| Withdrawn | 1962 |
| Wheel Arrangement | 4w Bogies |
| Number | Altnumber | Status | Note | Livery | Location | Base | Owner | RHRP | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1145 | W1145W 079038 | S | The Great Western (SVR) Association Shop | Chocolate and Cream | Severn Valley Railway | Great Western (SVR) Assoc. | 1922 | 1973 | |||
| 1150 | W1150W DW150241 | S | Poor condition | Chocolate and Cream | International Metals and Cable Recycling Ltd | CarriageInfo.asp?Ref=104 | 1922 | 1984 | |||
| 261 | W261W | S | Staff accommodation | Brown | Highley | Severn Valley Railway | CarriageInfo.asp?Ref=62 | 1921 | 1961 |
Coach
Churchward
Churchward Bogie Gangway Full Brake (BG) Toplight (Diagram K36)
Extant Stock:
Number Range: W1157W - W1163W (7). Built Swindon Aug 1908 - Jan 1912 to Lot 1344.
W1159W - ex WW1 Ambulance Coach 3551. Renumbered DW150294 and converted to a Medical Examination Coach in 06/1961. Withdrawn 1975
| Diagram | K36/M33 |
| Introduced | 1911 |
| Builder | GWR Swindon |
| Length | 57' 0" |
| Width | 9' 0" |
| Withdrawn | 1961 |
| Wheel Arrangement | 4w Bogies |
| Weight | 28t 2cwt |
.jpg)
| Number | Altnumber | Status | Livery | Base | Owner | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|
| 1159 | W1159W 3551 DW150294 | R | Bare Wood | Didcot Railway Centre | Great Western Preservations Ltd | 1911 | 1975 |
Coach
Collett
Collett Bogie Gangwayed Full Brake (BG) Bow End Wide Stock (Diagram K40)
Extant Stock:
Number range: W1175W - W1184W (10). Built Swindon Mar 1936 - Apr 1936 to Lot 1413.
| Diagram | K40 |
| Length | 61' 4" |
| Width | 9' 0" |
| Introduced | 1930 |
| Withdrawn | 1967 |
| Wheel Arrangement | 4w 7' Bogies |
| Builder | GWR Swindon |
| Weight | 28t 0cwt |
| Number | Altnumber | Status | Livery | Base | Owner | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|
| 1184 | W1184W | R | Unknown | Didcot Railway Centre | Great Western Preservations Ltd | 1930 | 1962 |
Coach
Collett
Collett Bogie Gangwayed Full Brake (BG) Flat End Wide Stock (Diagram K41)
Extant Stock:
Number range: W111W - W120W (10). Built Swindon Sep 1934 to Lot 1512.
Number range: W181W - W200W (20). Built Swindon Nov 1935 - Dec 1935 to Lot 1535.
W111W - Renumbered 060790 for internal use in 08/1967. Withdrawn in 1972
W184W - Renumbered ADB975157 and converted to a CM&EE Stores Van in 06/1972. Withdrawn in 1987
W185W - Renumbered ADB975158 and converted to a CM&EE Stores Van in 01/1972. Withdrawn in 1987
| Diagram | K41 |
| Length | 57' 0" |
| Width | 9' 0" |
| Introduced | 1934 |
| Withdrawn | 1973 |
| Wheel Arrangement | 4w 9' Heavy Bogies |
| Builder | GWR Swindon |
| Weight | 28t 4cwt or 28t 11cwt |
| Number | Altnumber | Status | Note | Livery | Base | Owner | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|---|
| 111 | W111W 060790 | S | Brown | Didcot Railway Centre | Private | 1934 | 1972 | ||
| 184 | W184W ADB975157 | R | Brown | Cholsey & Wallingford Railway | 1935 | 1987 | |||
| 185 | W185W ADB975158 | D | Sales van | Chocolate and Cream | Gloucestershire Warwickshire Steam Railway | GWSR plc | 1935 | 1987 |
Coach
Collett
Collett Bogie Gangwayed Full Brake (BG) Flat End Standard Stock (Diagram K42)
Number range: W91W - W100W & W268W - W277W (20). Built Swindon Sep 1944 - May 1945 to Lot 1665.
Number range: W121W - W130W (10). Built Swindon May 1940 - Jun 1940 to Lot 1652.
Number range: W158W - W167W (10). Built Swindon Nov 1937 - Dec 1937 to Lot 1604.
Extant Stock:
W98W - Withdrawn at Redbank Carriage Sidings, Manchester in 1977.
W276W - Renumbered ADB975640 and converted to a BTU Tool Van (Old Oak Common Breakdown Train) in 1977. Withdrawn in 1990.
| Introduced | 1944 |
| Builder | GWR, Swindon |
| Diagram | K42 |
| Length | 57' 0" |
| Width | 8' 11" |
| Withdrawn | 1978 |
| Wheel Arrangement | 4w 9' Bogies |
| Weight | 28t 5cwt |
| Number | Altnumber | Status | EVN | Livery | Location | Base | Owner | RHRP | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 276 | W276W ADB975640 | A | Carmine and Cream | South Devon Railway | South Devon Railway Trust | CarriageInfo.asp?Ref=63 | 1945 | 1990 | |||
| 98 | W98W | S | Workshop / Stores Van | Chocolate and Cream | Bewdley | Severn Valley Railway | The GWR 813 Preservation Fund | 1944 | 1977 |
Coach
Collett
Collett Bogie Gangwayed Parcels Brake Van (BG) Flat End Wide Stock (Diagram K41)
Extant Stock:
Number range: W61W - W70W (10). Built Swindon May 1941 - Aug 1941 to Lot 1667.
| Diagram | K44 |
| Length | 59' 10" |
| Width | 8' 11" |
| Introduced | 1941 |
| Withdrawn | 1978 |
| Wheel Arrangement | 4w 9' Bogies |
| Builder | GWR Swindon |
| Weight | 28t 10cwt |
| Number | Altnumber | Status | Livery | Location | Base | Owner | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|---|
| 64 | W64W | S | Chocolate and Cream | Off the B4352, north west of Blakemere village | Blakemere, Herefordshire | Private | 1941 | 1977 |
Coach
Hawksworth
Hawksworth Bogie Gangway Full Brake (BG) BR Built (Diagram K45)
Extant Stock:
Number range: W290W - W299W (10). Built Swindon Dec 1949 to Lot 1722.
Number range: W300W - W324W (25). Built Swindon Mar 1950 - Nov 1950 to Lot 1740.
W297W - Renumbered ZDW150354 and converted to a Cinema Equipment Coach in 1958. Withdrawn in 1985c
| Diagram | K45 |
| Length | 64' 0" |
| Width | 8' 11" |
| Introduced | 1949 |
| Withdrawn | 1978 |
| Wheel Arrangement | 4w 9' Bogies |
| Builder | GWR Swindon |
| Weight | 30t 6cwt |
.jpg)
| Number | Altnumber | Status | Note | Livery | Base | Owner | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|---|
| 297 | W297W ZDW150354 | S | Brown | Northampton & Lamport Railway | Private | 1949 | 1985c | ||
| 316 | W316W | S | Volunteer facility | Chocolate and Cream | Didcot Railway Centre | Great Western Preservations Ltd | 1950 | 1977 |
Coach
Hawksworth
Hawksworth Bogie Gangwayed Full Brake (BG) BR Built Standard Stock (Diagram K46)
Number range: W325W - W334W (10). Built Swindon Jun 1951 - Jul 1951 to Lot 1752.
| Diagram | K46 |
| Length | 64' 11" |
| Width | 8' 11" |
| Introduced | 1951 |
| Withdrawn | 1979 |
| Wheel Arrangement | 4w 9' Bogies |
| Builder | GWR Swindon |
| Weight | 28t 16cwt |
.jpg)
| Number | Altnumber | Status | Note | Livery | Location | Base | Owner | RHRP | In Service | Withdrawn | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 333 | W333 | S | Brown | Didcot Railway Centre | Great Western Society Ltd | 1951 | 1978 | ||||
| 334 | W334 172 | D | Camping Coach | Green and Cream | Goathland | North Yorkshire Moors Railway | North Yorkshire Moors Railway | CarriageInfo.asp?Ref=69 | 1951 | 1978 |
