    PH: Diesel Loco: 900

    Diesel Loco

    901-905, 908 are 1st version General Electric U15C models.

    906-907, 909-916 are 1st version General Electric U14C models.

    917-922 are 2nd version General Electric U15C models.

    Gauge 1067 mm (3 ft 6 in)
    Length 17.00 m (56 ft)
    Width 2.753 m (9 ft 0.4 in)
    Height 3.874 m (12 ft 8.5 in)
    Introduced 1973 (901-905/908); 1979 (906-907/909-916); 1991 (917-922)
    Wheel Arrangement Co-Co
    Builder General Electric
    Power 1560hp (902 and 919 are derated to 1400hp)
    Weight 53.52 t (118000 lbs)
    TE Starting: 57000 lb at 30%; Continuous: 54300 lb at 8mph.
    Engine GE 7FDL-8 4 stroke V8
    Transmission 93/18 gear ratio
    Max Speed 103 km/h (64mph)
    Driving Wheel Dia 914 mm (36 ins)
    Wheelbase 3.188 m (10 ft 5.5 in) per bogie

    Photo: ~

    Submit Photo

    Your photo will be submitted to the editors for approval.

    • You must ensure you have permission of the copyright owner to submit this photo for SpotLog
    • Please do not submit photo's taken from Wikipedia or another website unless you have explicit permisson to do so
    • Putting a date in the photo caption is often helpful
    • Upload must be in JPEG format
    Number Altnumber Status Note Livery Depot Owner
    901 X Philippine National Railways
    902 Blue with red lining Tayuman Philippine National Railways
    903 X Philippine National Railways
    905 X Collided with 910 between Hondagua and Tagkawayan 31/12/1983, and scrapped. Philippine National Railways
    906 O Awaiting repairs. Blue with red lining Philippine National Railways
    907 X Philippine National Railways
    908 904   X This is the second loco to carry no. 908. Scrapped in 2009. Red with yellow lining Philippine National Railways
    909 X Blue with red lining Philippine National Railways
    910 X Collided with 905 between Hondagua and Tagkawayan 31/12/1983, and scrapped. Philippine National Railways
    911 O Awaiting repairs. Blue with red lining Caloocan Philippine National Railways
    912 X Bombed by the New People's Army. Philippine National Railways
    913 Caloocan blue with gold lining Caloocan Philippine National Railways
    914 A Caloocan blue with gold lining Caloocan Philippine National Railways
    915 O Awaiting repairs. Blue with red lining Caloocan Philippine National Railways
    916 908   A Renumbered 916 in 1989 after being attacked with bullets and a grenade following an incident involving the death of an Army person's son. Blue with red lining Tayuman Philippine National Railways
    917 A Orange Tayuman Philippine National Railways
    918 A Overhauled by MRail-MDJV. Blue with red lining Naga Philippine National Railways
    919 Overhauled by MRail-MDJV. Caloocan blue with gold lining Tayuman Philippine National Railways
    920 W Crashed into a dump truck at Sumulong Crossing, Quezon City in 2001 and withdrawn. Blue with red lining Philippine National Railways
    921 A Overhauled by MRail-MDJV. Caloocan blue with gold lining Caloocan Philippine National Railways
    922 A Caloocan blue with gold lining Naga Philippine National Railways
