    Test: Steam Locomotive: 63

    Steam loco

    The SR Merchant Navy class (originally known as the 21C1 class, and later informally known as Bulleid Pacifics, Spam Cans – which name was also applied to the Light Pacifics – or Packets) is a class of air-smoothed 4-6-2 (Pacific) steam locomotives designed for the Southern Railway by Oliver Bulleid. The Pacific design was chosen in preference to several others proposed by Bulleid. The first members of the class were constructed during the Second World War, and the last of the 30 locomotives in 1949.

    Incorporating a number of new developments in British steam locomotive technology, the design of the Merchant Navy class was among the first to use welding in the construction process; this enabled easier fabrication of components during the austerity of the war and post-war economies. In addition, the locomotives featured thermic syphons in their boilers and the controversial Bulleid chain-driven valve gear. The class members were named after the Merchant Navy shipping lines involved in the Battle of the Atlantic, and latterly those which used Southampton Docks: a publicity masterstroke by the Southern Railway, which operated Southampton Docks during the period.

    Due to problems with some of the more novel features of Bulleid's design, all members of the class were modified by British Railways during the late 1950s, losing their air-smoothed casings in the process. The Merchant Navy class operated until the end of Southern steam in July, 1967. A third of the class has survived and can be seen on heritage railways throughout Great Britain. They were known for reaching speeds of up to 105 mph (167 km/h); such speeds were recorded by examples including No. 35003 Royal Mail (since scrapped) and Nos. 35005 Canadian Pacific and 35028 Clan Line (both preserved).

    Wheel Arrangement 4-6-2
    Length 69'8''
    Introduced 1941
    Builder Southern Railway
    TE 37,515 lbf
    Driving Wheel Dia 6'2''
    Boiler Pressure 280psi
    Num Cylinders 3
    Valve Gear Walschaerts
    Cylinder Dimensions 18" * 24"

    photo of the loco in question taken by Mark

    Photo: MRG

    Submit Photo

    Your photo will be submitted to the editors for approval.

    • You must ensure you have permission of the copyright owner to submit this photo for SpotLog
    • Please do not submit photo's taken from Wikipedia or another website unless you have explicit permisson to do so
    • Putting a date in the photo caption is often helpful
    • Upload must be in JPEG format
    Number Alt number Name Status Pool Depot Note
    63001 Chippenham W
    63002 Castle Cary
    63005 Colergne
    63010 Calne
    63011 Devizes P
    63012 Warminster
    63013 Pewsey X
    63014 Wotton BAsset
    63015 Melksham
    63016 Malmesbury
    63017 X
    63018
    63019
    63020 Westbury
    63021
    63022
